| Brand Name : | SY |
| Model Number : | GW245-A |
| Certification : | FCC/CE/ROSH |
| Price : | US$19-US$22/PC |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 3000 pieces per week |
| Delivery Time : | 5-8 working days |
| Feature | Description | Comments |
| CPU | ZX297520V3 | |
| Standard | 3GPP Release 9 | |
| UE Category | CAT.4 | |
| Wi-Fi | 2.4 GHz | 802.11 b/g/n compliant |
| LED Indicators | Wi-Fi/Signa | |
| SIM | 4FF USIM | support 1.8V / 3.0V |
Reset Button | Tact switch x1 | |
| Power Supply | USB input: 5v-1a, electric power 2W | |
Optional. Extra cost required |
| Dimension | 88*28*12.3mm |
| Weight | 25g |
Feature | Capability | Comments | |||
| Min | Typ | Max | Unit | ||
| LTE Max Transmit Power | 22 | dBm | Compliant with 3GPP with margin | ||
| LTE Receiver Sensitivity (FDD) | -93 | dBm | Compliant with 3GPP with margin | ||
LTE Antenna Support Frequency | 703 | 2690 | MHZ | ||
| Wi-Fi Channel @ 2.4GHz | Ch 1~13 | ||||
2.4GHz Wi-Fi Channel BW | 20/40 | MHZ | |||
| Wi-Fi Power level | 14 | dBm | 11b | ||
| 13 | dBm | 11g | |||
| 11 | dBm | 11n | |||
| Wi-Fi Sensitivity 11n | ≤- 69 | dBm | |||
| Feature | Standard | Capability | Comments |
| Immunity to ESD | EN 61000 -4-2 | Compliant | Air +/8 KV; Contact +/-4KV |
| Immunity to burst | EN 61000 -4-4 | Compliant | L/N/L-N+/-1KV |
| Immunity to surge | EN 61000 -4-5 | Compliant | L-N+/-1KV |
| Immunity to Conducted RF disturbances | EN 61000 -4-6 | Compliant | 0.15-80 MHz |
| Immunity to Voltage Dips and short interruption | EN 61000 -4-11 | Compliant | |
| Harmonic current emissions | EN 61000 -3-2 | Compliant | |
| Voltage fluctuations and flicker | EN 61000 -3-3 | Compliant | |
| Conducted emission test, class-B | EN 55022 | Compliant | 0.15-30 MHz |
|
|
